Architectural Aluminium Glazing Products
  • Baxter College
  • Baxter College
  • Baxter College
  • Baxter College

Project Details

  • Client: Baxter College
  • Main Contractor: Ali Systems
  • Photos: Ali Systems

Products Supplied

  • Sapa 202 commercial door system. Adams rite hook lock, pocket screens Automatic door gear, record E-STA sliding door gear, inside cover, monitored battery backup, multi programmable function switch, side screen safety sensor, activation/threshold sensors, first entry key switch.
  • Sapa ST2 thermally broken door system. Concealed overhead closers (hold open), anti finger trap - 300mm plain pad handles (inside and out), hook lock, Europrofile cylinders, key both sides, low level threshold, flush bolts to slave leaf of double doors.
  • Sapa Dualframe 75mm window system - 155 or 100mm cills as noted. Trickle vents, butt hinges, folding cam openers, teleflex winding gear fitted as shown.
  • Sapa Dualslide horizontal sliding windows. Steel rollers,iIntegral finger pulls, latch lock, Flydor fly mesh to inside.
  • Sapa 75mm Si window system. Horizontal pivot windows, pivot hinges, multipoint locking, locking handles (silver) - 155mm cills.
  • All Sapa windows and doors provided in project colour - RAL7016m (anthracite grey)
  • Glazing used: 28mm clear 6.4mm laminated low E softcoat, 28mm obscure (stippolite) 6.4mm laminated low E softcoat and 28mm aluminium faced insulated panels powder coated to match frame colour.
